REMOTE CONTROL
267
CONFigure[:VOLTage][:DC]:RATio
Sets measurement to DCV ratio mode on the 1
st
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF),
Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF:VOLT:DC:RAT 1
Sets the DC voltage range to 1V using the default resolution.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
CONFigure[:VOLTage]:AC
Sets measurement to AC Voltage on the 1
st
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF:VOLT:AC
Sets the AC voltage range to auto range.
CONFigure:CURRent[:DC]
Sets measurement to DC Current on the 1
st
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX |
DEF),Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF:CURR:DC 10e-3,DEF
Sets the DC current range to 10mA using the default resolution.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
CONFigure:CURRent:AC
Sets measurement to AC Current on the 1
st
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF:CURR:AC 10e-2
Sets the measurement mode to AC Current with a 100mA range.
