GDM-906X Series User Manual
266
CALCulate:TRANsform:HISTogram:RANGe:LOWer?
Returns the lower range value of the histogram function.
Return parameter: <NRf>
CALCulate:TRANsform:HISTogram:RANGe:UPPer
Sets the upper range value of the histogram function.
Parameter: <NRf> (-1.0E+15 ~ 1.0E+15) | MIN | MAX | DEF
Example: CALC:TRAN:HIST:RANG:UPP 1.0
Sets the upper range value to 1.0
CALCulate:TRANsform:HISTogram:RANGe:UPPer?
Returns the upper range value of the histogram function.
Return parameter: <NRf>
CALCulate:TRANsform:HISTogram[:STATe]
Turns the histogram function on/off.
Parameter: 0 | 1 | ON | OFF
Example: CALC:TRAN:HIST:STAT OFF
Turns the histogram function OFF.
CALCulate:TRANsform:HISTogram[:STATe]?
Returns the histogram function state.
Return parameter: 0 | 1, 1=ON, 0=OFF
CONFigure Commands
CONFigure?
Return current function,range and resolution.
Example: CONF:VOLT:DC 10,MIN
CONF?
Rereuns: ”VOLT +1.00000000E+01,+1.00000000E-05”.
CONFigure[:VOLTage]:DC
Sets measurement to DC Voltage on the 1
st
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX |
DEF),Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF:VOLT:DC 1,MAX
Sets the voltage range to 1V and the resolution to the maximum.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
