GDM-906X Series User Manual
66
Editing 1st or 2nd
measurement item
settings
After the secondary measurement function has been
activated, the rate, range and measurement item can be
edited for either the primary or secondary display. Note,
however, it is more practical to configure the first or
second measurement items before activating dual
measurement mode.
To edit measurement parameters in dual measurement
mode, you must first set which display is the active
display. The orange outline covering either 1ST or 2ND
icon indicates the active display.
Toggle the active display between
the 1ST and 2ND display by
pressing the Knob key:
Primary display: 1ST highlighted in
orange outline.
Secondary display: 2ND highlighted
in orange outline.
1ST in active display:
2ND in active display:
2. Edit active
display settings
Edit the range, rate or measurement
item for the active display in the
same way as for single measurement
operation. See the Basic
Measurement on page 26 for details.
To turn Off the 2ND measurement,
first toggle in 1ST active display
followed by pressing the F6 (2ND)
key. Click the F6 (OFF) key again to
disable the 2ND measurement.
