Harris Constellation - RELAYS from the CONFIGURATION Submenu; Table 5-9: RELAYS Submenu

Harris Corporation Constellation™
RELAYS from the CONFIGURATION Submenu 5-11
CONFIGURING THE
CONSTELLATION
RADIO
RELAYS from the CONFIGURATION
Submenu
• There are a list of
– 8 relay outputs
– 17 alarm configurations
• Defaults
–For RELAY 1 , MAJOR ALARM is the default.
–For
RELAY 2 , MINOR ALARM is the default.
Table 5-9: RELAYS Submenu
RELAYS
Submenu
Selection Explanation
RELAY 1 TO
RELAY 8
INPUT
Manual Control
(external site
control)
Major Alarm
Minor Alarm
Input LOS
Sync Loss A
Sync Loss B
Errored Seconds A
Errored Seconds B
Signal Degradation
A1
Signal Degradation
A2
Signal Degradation
B1
Signal Degradation
B2
On Line Mod/Tx A
On Line Mod/Tx B
On Line Rx A
On Line Rx B
On Line HLM
Select the alarm defined for the Relay
number.
