Constellation Port Descriptions 7-7
SNMP-BASED
NETWORK
MANAGEMENT
Table 7-3: Standard Configuration
Setting
Constellation
#1
Constellation
#2
Constellation
#3 (top)
Constellation
#3 (bottom)
Keypad:
... Network Management > IP Routing
AUX Port Config Ethernet Netcom Netcom Netcom
Netcom Interface Enabled Enabled Enabled Enabled
Netcom IP Address 192.168.2.1 192.168.2.2 192.168.2.3 192.168.2.4
Netcom Subnet Mask 255.255.255.0 255.255.255.0 255.255.255.0 255.255.255.0
Ethernet Interface Enabled Disabled Disabled Disabled
Ethernet IP Address 192.168.1.2
255.255.255.255
(default)
255.255.255.255
(default)
255.255.255.255
(default)
Ethernet Subnet Mask 255.255.255.0 255.255.255.255 255.255.255.255 255.255.255.255
IP Route 1...10
IP Route Mask 1...10
Next IP Router 1...10
RIP RIP II RIP II RIP II RIP II
RIP on Netcom IF Enabled Enabled Enabled Enabled
RIP on Ethernet IF Enabled Enabled Enabled Enabled
Keypad:
... IP Routing > SNMP > SNMP Managers
Manager 1IP Address 192.168.1.1 192.168.1.1 192.168.1.1 192.168.1.1
Manager 2…10 IP Address 255.255.255.255 255.255.255.255 255.255.255.255 255.255.255.255
Keypad:
... IP Routing > SNMP > Trap Destination
Trap Destination 1 192.168.1.1 192.168.1.1 192.168.1.1 192.168.1.1
Trap Destination 2…10 255.255.255.255 255.255.255.255 255.255.255.255 255.255.255.255
