Harris Corporation Constellation™
Keypad B-3
KEYPAD MENU
TREE
Pinout Table
Keypad
Technical Data
Table B-1: Pinouts
Signal
Keypad or VT-100
Terminal Emulator DE-9
(Pin Number)
Constellation
Backplane
RJ-45
(Pin Number)
No connection 1, 4, 5, 6, 7 3, 6, 8
Tx Data 2 4
Rx Data 3 5
Ground 5 2
Vcc (+5 Vdc) 9 1
Table B-2: Keypad technical data
Measurement
Dimension 5.5 x 3.38 x 0.75 in.
Weight 0.5 lb
Interface Type
Interface type RS-232
Connector
Connector DE-9, female
