Harris Corporation Constellation™
Tools and Test Equipment 11-3
FIELD-
REPLACEABLE
UNITS
Tools and Test Equipment
General Procedures
• If applicable, inform the network administrator of your plan.
• Place any defective unit in an antistatic bag, and return the unit to
Harris MCD.
Drawings with the following highlighted:
• Radio Frequency Section
• Signal Processing Section
Opening and Removing the Constellation Doors
1. To open the Constellation doors, lift up the two door latches and turn them
clockwise. See Figure 11-1.
Tools
Antistatic wrist and/or heel strap
SMA wrench (5/16 inch)
SMA torque wrench (8 in-lb)
Small hand tools
Test Equipment Used for
Power meter Transmitter Assembly replacement
Frequency counter
Transmitter Assembly or Receiver Assembly
replacement
Cable, SMA-SMA connectors, 3
to 6 feet (approx.)
Frequency counter
Digital voltmeter Measuring DC voltages
