Harris Constellation - Receiver Assembly

Harris Corporation Constellation™
Receiver Assembly C-3
HARDWARE
COMPATIBILITY
TABLES
Receiver Assembly
When replacing a receiver (Rx) assembly you must be sure that the option
numbers (last three digits of the part numbers) of the Multiplier-Filter and the
IF Filter in the replacement Rx are the same as the option numbers of the
Multiplier-Filter and IF Filter in the Rx that it replaces. See
“Multiplier-Filter”
on page C-4
and “IF Filter” on page C-4 .
Table C-2: History of Released Receivers and Compatibility
Rx
Frequency
Part Number &
Model
Released Sept. 1999
Part Number &
Model
Released Feb. 2001
Part Number &
Model
Released Feb. 2002 to
support the High
Capacity option
6 GHz
192-115039-001 / Model 2
Used in Low/Medium capacity
radios: 8xDS1/ 16xDS1/28xDS1
and DS3
Compatibility: This option
replaces models with part #
192-115039-001 / Model 2.
193-115039-001 / Model 3
Used in Low/Medium capacity
radios: 8xDS1/ 16xDS1/28xDS1
and DS3
Compatibility: This option
replaces models with the
following part #
• 192-115039-001 / Model 2
• 193-115039-001 / Model 3
193-115039-011 / Model 3
Used in High capacity radios
Compatibility: This option
replaces models with the
following part #:
• 193-115039-011 / Model 3
• 193-115039-001 / Model 3
a
• 192-115039-003 / Model 2
a
7/8 GHz
192-115039-003 / Model 2
Used in Low/Medium capacity
radios: 8xDS1/ 16xDS1/28xDS1
and DS3
Compatibility: This option
replaces models with part #
192-115039-003 / Model 2.
193-115039-001 / Model 3
Used in Low/Medium capacity
radios: 8xDS1/ 16xDS1/28xDS1
and DS3
Compatibility: This option
replaces models with the
following part #
• 192-115039-001 / Model 2
193-115039-001 / Model 3
193-115039-013 / Model 3
Used in High capacity radios
Compatibility: This option
replaces models with the
following part #:
• 193-115039-013 / Model 3
• 193-115039-003 / Model 3
a
• 192-115039-003 / Model 2
a
10/11 GHz
192-115039-002 / Model 2
Used in Low/Medium capacity
radios: 8xDS1/ 16xDS1/28xDS1
and DS3
Compatibility: This option
replaces models with part #
192-115039-002 / Model 2.
193-115039-001 / Model 3
Used in Low/Medium capacity
radios: 8xDS1/ 16xDS1/28xDS1
and DS3
Compatibility: This option
replaces models with the
following part #
• 192-115039-001 / Model 2
193-115039-001 / Model 3
193-115039-012 / Model 3
Used in High capacity radios
Compatibility: This option
replaces models with the
following part #:
• 193-115039-012 / Model 3
• 193-115039-002 / Model 3
a
• 192-115039-002 / Model 2
a
a. If you replace your Rx with one of these models, the RSL value shown in the keypad will be ~2.55
dB higher than the actual RSL (actual RSL does not change). The trigger point for the low RSL
alarm also will be off (late) by ~2.55 dB. A future software release will correct the RSL reading and
alarm trigger point.
