Constellation™ November 2003
B-2 Keypad Menu Tree
Cable
A cable (087-115028-001) is required to connect the Keypad to the radio’s
KEYPAD (RJ-45) serial port. This cable can also be used to connect the radio to
the 9-pin serial port on a VT-100 terminal or a PC with emulator.
Setting Up a PC with Emulator
The following is an example of how to set up the PC to communicate with the
radio.
From the Windows-based desktop, click on the
Start button and select
Programs
Accessories
Communication or Hyperterminal
In the dialog boxes that appear on the screen, type or select the correct
information.
In the Flow control box, select None.
Screen Format
Serial Interface
• 9600 bits/s
• 8 bits
• No parity
Alphanumeric Display Size
Keypad 4 lines by 20 columns
VT-100/PC screen 20 lines by 20 columns
To Next Page
