Harris Corporation Constellation™
Network Management 5-13
CONFIGURING THE
CONSTELLATION
RADIO
For more information on MODE, LOCAL OFF HOOK, and
EXTERNAL PILOT, refer to the Systems Application
Information (SAI) manual.
CONTROL Submenu
1. If it is required to mute the VF and data in the A direction, from the main
menu:
2. Select
CONTROL > SERVICE CHANNEL > DATA/VF A > MUTE
.
Notes:
• Default is ON.
• It is important not to connect two slave terminals with their external
pilot enabled if each terminal is part of a separate loop.
• At no time should a master site have its external pilot enabled; the
Service Channel will not work properly.
Network Management
For network management configuration, refer to Chapter 6 and Chapter 7
.
DATA PORT
BAUD
SAMPLE
9,600 /
19,200 /
38,400
Data rates up to 4,800 bit/s can be used with no
restriction on the size of the data byte.
For asynchronous start-stop, with the data
byte set to 8 bits.
DATA PORT
PARITY
ENABLE
To send the parity bit through the system.
The system does not monitor the parity bit.
Table 5-10:SERVICE CHANNEL submenu (continued)
SERVICE
CHANNEL
Submenu
Selection Explanation
