The power at the top of the rack (TOR) = the power
meter reading + the coupling loss shown on the monitor
port label.
Table 3-14:Power at antenna flange, NP configuration
TX
Freq.
(GHz)
Power (dBm)
8T 16T 28T/DS3 OC3/3xDS3/4xDS3
Std. High
ab
Std. High
ab
Std. High
a
6 29.5 28.5 29.5 29.0 30.5 29.0 31.5/31.0
c
7/8 27.5 26.5 27.5 27.0 28.5 27.5 30.0
10/11 26.0 24.5 25.5 25.0 26.5 25.0 28.5
a. High Power requires high power option of the Transmit Assembly.
b. High power requires high gain modem option (101-115540-002 for 16T and -003 for 28T).
c. The first number is for OC3 & 3xDS3; the second number is for 4xDS3.
Table 3-15:Power at antenna flange, MHSB configuration
TX
Freq.
(GHz)
Power (dBm)
8T 16T 28T/DS3 OC3/3xDS3/4xDS3
Std. High
ab
Std. High
ab
Std. High
a
6 29.1 28.1 29.5 28.6 30.1 28.6 31.1/30.6
c
7/8 27.1 26.1 27.1 26.6 28.1 27.1 29.6
10/11 25.6 24.1 25.1 24.6 26.1 24.6 28.1
a. High Power requires high power option of the Transmit Assembly
b. High power requires high gain modem option (101-115540-002 for 16T and -003 for 28T).
c. The first number is for OC3 & 3xDS3; the second number is for 4xDS3.
