Harris Corporation Constellation™
Detailed Terminal Test 3-31
INSTALLATION
AND
COMMISSIONING
Figure 3-20: Location of the transmit monitor port
Power Meter Reading
a. The Power Meter reading should equal the value from
Table 3-14 or Table 3-15 minus the Coupling Loss on the label.
Power may be set low in some applications. High power
settings require a high power option of the transmit
assembly.
Label:
COUPLING LOSS FROM
ANTENNA FLANGE
CAL AT
XMT FREQ
Transmit monitor port
