Harris Constellation - Figure A-11: RJ-11, FSCAN, DE-9, and BNC Connector Specifications

Harris Corporation Constellation™
Customer Access Areas A-11
WIRING
SPECIFICATIONS
Figure A-11: RJ-11, FSCAN, DE-9, and BNC connector
specifications
HAND SET 1, J25
NC HAND SET R HAND SET T NC
1
3
4
5
6
2
NC HAND SET R HAND SET T NC
1
3
4
5
6
2
HAND SET 2, J32
DCD RMT GND RTS RMT TX DATA RMT RX DATA RMT CTS RMT GND DTR RMT
1
3
4
5
6
7
82
FSCAN, J28
75 ohm
TX DS3
75 ohm
RX DS3
75 ohm
75 ohm
DS3 IN
DS3 OUT
E1
WAYSIDE OUT
E1
WAYSIDE IN
DE-9 (female)
1
3
4
5
6
7
8
9
2
GND
DTR RMT
TX DATA RMT
RX DATA RMT
DCD RMT
NC
CTS RMT
RTS RMT
NC
P
P
(not available for 3xDS3/
4xDS3)
