Harris Constellation - Radio Frequency Section; Figure 11-8: Radio Frequency Section, Repeater

Constellation™ November 2003
11-8 Field-Replaceable Units
Radio Frequency Section
Figure 11-8: Radio Frequency section, repeater
TRANSMITTER A1 RECEIVER A1
ACU
FUSE PANEL
FAN ASSEMBLY
POWER SUPPLY A1
M12
Units not
used for
DS3
config-
uration
TRANSMITTER B1 RECEIVER B1
ACU
FUSE PANEL
FAN ASSEMBLY
POWER SUPPLY B1
KEYPAD, HANDSET, AND
DS1 ACCESS
TRANSMITTER A2 RECEIVER A2
POWER SUPPLY A2
TRANSMITTER B2 RECEIVER B2
POWER SUPPLY B2
