Harris Corporation Constellation™
Signal Processing Section 11-35
FIELD-
REPLACEABLE
UNITS
Installing the M12 Unit
1. Check the part number of the M12 Unit to ensure that the correct unit is
being installed.
2. Ensure that the extractor on the M12 Unit is in the unlocked position.
3. Carefully slide the unit into the designated slot in the shelf until the unit
plugs into the backplane.
This procedure causes a hit.
4. Push the extractor to lock the unit into place.
5. For a MHSB unit, use the Keypad command to release the Standby Unit.
CONTROL > LOCK/IF LPBK > RELEASE STBY, EXEC
