SNMP-BASED NETWORK
MANAGEMENT
Introduction
The Constellation radio has an embedded SNMP agent on board. It also has a
10BASE-T Ethernet interface. This makes it easy to connect Constellation to
NetBoss, StarView or any other SNMP-based network management system.
Constellation is typically configured using the keypad. It can also be configured
using serial connection and a hyperterminal connection from a PC or laptop.
Constellation should have the latest software installed
and running before completing the following.
Constellation Port Descriptions
The ports on the customer access area of the Constellation backplane are shown
in Figure 7-1. The tables on the following pages describe the connector type and
function.
For the purpose of this document, we will focus on the Ethernet port (J31).
