Harris Corporation Constellation™
Summary of the Installation Procedures 3-7
INSTALLATION
AND
COMMISSIONING
Summary of the Installation Procedures
Table 3-4 is a summary of the installation procedures.
Table 3-4: Installation procedures
Step Procedure
For Details,
Go To
1
Ensure that the power breaker is off or that the fuse is
removed.
2
Install the Constellation Radio rack as specified in the
Sales Order Specific Information (Engineering Work
Order).
3
Ground the radio rack. page 3-11
4
Open and remove the Constellation doors. page 3-11
5
Connect the interconnection cables to the
Constellation backplane.
page 3-14
6
Connect the Constellation radio to other equipment. Appendix A
7
Connect the customer-configured alarm wires. page 3-18
8
Connect the Constellation to the antenna or to a
dummy load.
page 3-18
9
Test the office battery voltage. page 3-21
10
Connect the battery power wires to the Constellation. page 3-22
