Harris Corporation Constellation™
Downloading New Software 9-3
SYSTEM
SOFTWARE
UPGRADES
Figure 9-1: Local and remote download connections
Requirements
• IBM PC-compatible desktop or laptop computer
• Windows 95, 98, ME NT or 2000 operating system with adequate
resources
• Null cable for connecting the PC to the Constellation radio
- DE-9 to DE-9 cable (crossover cable)
- DE-9 to RJ-45 cable
See
Appendix A for pinout specifications.
Sliding window:
(2 x n + 1) = 3
n = 1
Sliding window:
(2 x n + 1) = 5
n = 2
Sliding window:
(2 x n + 1) = 7
n = 3
Sliding window:
(2 x n + 1) = 9
n = 4
