Constellation™ November 2003
B-10 Keypad Menu Tree
Configuration Submenu
M12-1/5 T2 ADD/DRP None/T2-1/.../T2-7
M12-1/5 DROP&CONT*** Drop&Cont***/Drop A/Drop B
M12-2/6 T2 ADD/DRP None/T2-1/.../T2-7
M12-2/6 DROP&CONT*** Drop&Cont***/Drop A/Drop B
M12-3/7 T2 ADD/DRP None/T2-1/.../T2-7
M12-3/7 DROP&CONT*** Drop&Cont***/Drop A/Drop B
M12-4/8 T2 ADD/DRP None/T2-1/.../T2-7
M12-4/8 DROP&CONT*** Drop&Cont***/Drop A/Drop B
M12-1... 4 T2 ADD/DRP None/T2-1/... /T2-7
SYSTEM
ADM
NETWORK
MANAGEMENT
TRIBUTARIES
RELAYS
SERVICE
CHANNEL
3DS3 CAPACITY USE* T3-1, T3-2, T3-3/
T2 ADM, T3-2, T3-3/
T3-1, T2 ADM, T3-3/
T3-1, T3-2, T2 ADM/
28 T1, T3-2, T3-3/
T3-1, 28 T1, T3-3/
T3-1, T3-2, 28 T1
USED CAPACITY 4xTRIB/8xTRIB/12xTRIB/16xTRIB/
20xTRIB/24xTRIB/28xTRIB
PROTECTION A, B UNPROT/UNPR TX/MHSB/FREQ DIV
SYNCHRONIZATION MX THRU TIMED/SOURCE
STUFFING MODE M13/C-BIT PARITY
TX A, B, ATPC ** DISABLE HIGH / DISABLE LOW /
ENABLE
M12 PROTECTION NON REV/REVERTIVE
SVC OPTION INSTALL / UNINSTAL
FAN OPTION INSTALL / UNINSTAL
PATH A, B ALARMS MENU HIDE/SHOW
CONFIG ALARM CLR/SET
ENABLE
CODE
EQUALIZER
DS3-1,2,3,4 INPUT ALARMS ENABLE/DISABLE
TRIBUTARY A1... A28 ENABLE/DISABLE
TRIBUTARY B1... B16 ENABLE/DISABLE
WAYSIDE ENABLE/DISABLE
TRIBUTARY A1 CODE AMI / B8ZS, HDB3
TRIBUTARY A28 CODE AMI / B8ZS, HDB3
TRIBUTARY B1 CODE AMI / B8ZS, HDB3
TRIBUTARY B16 CODE AMI / B8ZS, HDB3
WAYSIDE CODE AMI / B8ZS
WAYSIDE CODE AMI / B8ZS, HDB3
.
.
.
.
.
.
DS3 EQUALIZER 0-120’/120’-450’
DS3 1, 2, 3, 4 EQUALIZER 0-120’/120’-450’
TRIB A1... A28 EQUALIZER
TRIB B1... B16 EQUALIZER
WAYSIDE EQUALIZER 0-133’/ 133’-266’/ 266’-399’/
399’-533’/ 533’-655’
WAYSIDE EQUALIZER T1 0-133’/
T1 133’-266’/ T1 266’-399’/
T1 399’-533’/ T1 533’-655’/
E1 UNBALANCED/
E1 BALANCED
To gain access to
the hidden RF
Configuration menu:
Keypad: F1 + F3
VT100: CTRL B
NE ADDRESS 001 … 999
IP ROUTING
NETCOM OVER ETHERNET DISABLE/ENABLE
SNMP
COMM PORT SETTINGS
REBOOT SYSTEM NO/YES
AUX PORT CONFIG Netcom/Ethernet/None
NETCOM IP INTERFACE Disable/Enable
NETCOM IP ADDRESS xxx.xxx.xxx.xxx
NETCOM IP MASK xxx.xxx.xxx.xxx
ETHERNET IP INTERFACE Disable/Enable
ETHERNET IP ADDRESS xxx.xxx.xxx.xxx
ETHERNET IP MASK xxx.xxx.xxx.xxx
RIP Disable/Ver 1/Ver 2/Ver 1&2
RIP ON NETCOM IF Disable/Enable
RIP ON ETHERNET IF Disable/Enable
IP ROUTE 1 ADDRESS xxx.xxx.xxx.xxx
IP ROUTE MASK 1 xxx.xxx.xxx.xxx
NEXT IP ROUTER 1 xxx.xxx.xxx.xxx
IP ROUTE 7 ADDRESS xxx.xxx.xxx.xxx
IP ROUTE MASK 7 xxx.xxx.xxx.xxx
NEXT IP ROUTER 7 xxx.xxx.xxx.xxx
.
.
.
VERSAT BAUD 1200/2400/4800/9600
VERSAT PARITY None/Odd/Even
VERSAT DRIVER RS-232/RS-423
REMOTE BAUD 1200/2400/4800/9600/
19200/38400/57600
REMOTE PARITY None/Odd/Even
FARSCAN BAUD 1200/2400/4800/9600/
19200/38400/57600
FARSCAN PARITY None/Odd/Even
ADDRESS 000-999
MODE LINEAR / LPMASTER/
LP SLAVE
VF PORT 1 LEVEL -16dBm/7dBm or
0dBm/0dBm
VF PORT 2 LEVEL 0dBm/0dBm or
7dBm/-16dBm
DATA BRIDGE ISOLATE/BRIDGE
LOCAL OFF HOOK DISABLE/ENABLE
EXTERNAL PILOT DISABLE/ENABLE
DATA PORT A, B BAUD SAMPLE/9600/19200/38400
DATA PORT A, B PARITY DISABLE/ENABLE
** You can select one of the three options:
DISABLE HIGH: Disable ATPC, set Tx at High power.
DISABLE LOW: Disable ATPC, set Tx at Low power.
ENABLE: Enable ATPC.
*** DROP&CONT: Traffic can be dropped from both A and B at the same
time.
RELAY 1 INPUT
RELAY 8 INPUT
.
.
.
E
G
Manual Control
Major Alarm
Minor Alarm
Input LOS
Sync Loss A, B
Errored Second A, B
Signal Degrad A1, A2, B1, B2
On Line Mod/TX A, B
On Line RX A, B
On Line HLM
F
0-133’/ 133’-266’/
266’-399’/ 399’-533’/
533’-655’/ E1
*The 3DS3 CAPACITY USE submenu is used for the 4DS3 option as well as the 3DS3 option.
