Constellation™ November 2003
7-10 SNMP-Based Network Management
Based on Figure 7-3, the following assumptions are made:
• Four subnets are needed (one for each Ethernet subnet at each remote
site, and one for Netcom).
• Private class C IP (192.168.1-4.0) is used.
• StarView PC: 192.168.1.1
• Constellation #1 Ethernet IP: 192.168.1.2
• Constellation #1 Netcom IP: 192.168.2.1
• Constellation #2 Netcom IP: 192.168.2.2
• Constellation #3 (top) Netcom IP: 192.168.2.3
• Constellation #3 (bottom) Netcom IP: 192.168.2.4
• Constellation #2 Ethernet IP: 192.168.3.1
• Constellation #3 (bottom) Ethernet IP: 192.168.4.1
An advanced configuration would have the following (differences between
standard and advanced are in bold text):
All IP configurations are found in the following keypad
menu:
Configuration > Network Management
Table 7-4: Advanced Configuration
Setting
Constellation
#1
Constellation
#2
Constellation
#3 (top)
Constellation
#3 (bottom)
Keypad: ... Network Management > IP Routing
AUX Port Config Ethernet Ethernet Netcom Ethernet
Netcom Interface Enabled Enabled Enabled Enabled
Netcom IP Address 192.168.2.1 192.168.2.2 192.168.2.3 192.168.2.4
Netcom Subnet Mask 255.255.255.0 255.255.255.0 255.255.255.0 255.255.255.0
Ethernet Interface Enabled
Enabled Disabled Enabled
Ethernet IP Address 192.168.1.2
192.168.3.1 255.255.255.255
(default)
192.168.4.1
Ethernet Subnet Mask 255.255.255.0 255.255.255.0 255.255.255.255 255.255.255.0
IP Route 1...10
IP Route Mask 1...10
