Harris Constellation - Control Submenu

Harris Corporation Constellation™
The Menu Tree B-9
KEYPAD MENU
TREE
Control Submenu
LOCK/IF LPBK
TRIB LOOPBACK
TRIB REMOTE LPBK
WAYSIDE LPBK
RELAYS
SERVICE CHANNEL
ALTERNATE S/W
DATA/VF A, B XXX MUTE/ON
S/W VER XXXX
ALTERN S/W VER XXXX
RUN ALTERNATE SW EXEC
PROTECT M12-1... 8 XXX SET/CLR
RELEASE STBY EXEC
LOCK HLM-1, 2 XXX SET/CLR
LOCK MOD/TX-A1 A2 XXX SET/CLR
LOCK MOD/TX-B1, B2 XXX SET/CLR
LOCK DMOD/RX-A1, A2 XXX SET/CLR
LOCK DMOD/RX-B1, B2 XXX SET/CLR
MODEM-A, B IF LPBK XXX SET/CLR
SWITCH MOD/TX-A * EXEC
RCS SW A1 TO A2 ** CLR
RCS SW A2 TO A1 ** CLR
SWITCH MOD/TX-B * EXEC
RCS SW B1 TO B2 ** CLR
RCS SW B2 TO B1 ** CLR
TRIB A1 RMT LPBK XXX SET/CLR
TRIB A28 RMT LPBK XXX SET/CLR
TRIB B1 RMT LPBK XXX SET/CLR
TRIB B16 RMT LPBK XXX SET/CLR
.
.
.
.
.
.
RELAY 1... 8 XXX SET/CLR
DS3 LPBK XXX SET/CLR
TRIB A1 LPBK XXX SET/CLR
TRIB A28 LPBK XXX SET/CLR
TRIB B1 LPBK XXX SET/CLR
TRIB B16 LPBK XXX SET/CLR
.
.
.
.
.
.
D
* The SWITCH MOD/TX
command can be executed only
if there are no alarms on the off-
line Transmitter.
** If executing the SWITCH
MOD/TX command causes a
Remote Sync alarm (RCS
switch alarm), the command to
clear the RCS switch appears
on the screen.
WAYSIDE LPBK XXX SET/CLR
WAYSIDE RMT LPBK XXX SET/CLR
To gain access to the
hidden Control submenu:
Keypad: F1 + F3
VT100: CTRL B
OC3 LPBK XXX SET/CLR
OC3 RMT LPBK XXX SET/CLR
DS3-1, 2, 3, 4 LPBK XXX SET/CLR
DS3-1, 2, 3, 4 REM LPBK XXX SET/CLR
WARNING: These
commands may
interrupt traffic.
See instruct manual.
