Harris Corporation Constellation™
Turning on the Radio 3-9
INSTALLATION
AND
COMMISSIONING
Summary of the Terminal Test
Table 3-6 is a summary of the terminal test procedures.
Table 3-6: Terminal test procedures
Step Procedure
For Details,
Go To
Reference Frequency
1
At the Transmitter Assembly, measure the reference
frequency.
page 3-25
2
Measure the reference frequency at the Receiver
Assembly.
page 3-28
Transmitter Power Measurement
3
Use a Power Meter and the Keypad to verify the RF
transmitter power output at the transmit monitor
port.
page 3-30
Antenna Alignment
4
Ensure that the antenna is terminated into the
antenna system (and not to a dummy load).
Align the antenna at the Receiver Assembly.
page 3-35
Loopback Tests
5
Perform loopback tests (through the Keypad). page 4-1
BER Tests
6
Perform BER tests from the Keypad
PERFORMANCE > TRIBUTARY
To Next Page
