Harris Constellation - Page 148

Constellation™ November 2003
8-14 Routine Maintenance
Assembly
What to
Measure
Faceplate
Test Point
Unit
First
Installation
1 Year after
Installation
2 Years after
Installation
3 Years after
Installation
4 Years after
Installation
5 Years after
Installation
Initial Value
Date &
Name
Value
Date &
Name
Value
Date &
Name
Value
Date &
Name
Value
Date &
Name
Value
Date &
Name
Reference frequency
REF MON SMA connector (100 MHz)
A1 A2 B1 B2
Received Signal Level
Take th e reading from the Keypad
A1 A2 B1 B2
Page 2 of 2
Receiver
NOTES: 1. Measurements at the Receiver Assembly are not required by
the FCC. This page is for customer’s information only.
2. Refer to
Chapter 8
for procedures.
