DETAIL STATUS Target
Selection of the DETAIL STATUS command target on the UCN Status display invokes either the NIM
Detail Status display as shown in Figure 91 or the HPM Status display as shown in Figure 109.
System Error Journal Messages
In an Enhanced Universal Control Network (EUCN), the FTE cable errors reported in HM error
messages are interpreted in the same way as the UCN cable errors.
3.5 HPM Status Displays
Introduction
The following subsections describe the selection procedures for the HPM Status display, and its
associated displays. The status, statistics, and targets on the displays are also described.
HPM Status Displays
The HPM Status display is shown in the following figure. The display is obtained by selecting the
<SYST STATS> (System Status) key on the console and then selecting the PROCESS NETWORK
STATUS target on the display for the network you wish to examine. Choose the High-Performance
Process Manager associated with the HPMM to be displayed. Select the DETAIL STATUS target to
obtain the HPMM Status display.
Figure 109 HPM Status Display
To Next Page
