Honeywell HPM - Llmux IOP Detail Status Display; Figure 164 Analog Output IOP Detail Status Display - DISABLE CALIBRATN Target Selected

3 UCN Status Displays
3.8 IOP Detail Status Displays
284 HPM High-Performance Process Manager Service R688
Honeywell December 2020
DISABLE CALIBRATN target
Figure 164 Analog Output IOP Detail Status Display – DISABLE CALIBRATN Target
Selected
LLMux IOP Detail Status Display
IOP calibration
The Low Level Multiplexer (LLMux) IOP Detail Status display can be used for calibration of the
LLMux A/D converters. Targets are provided to enable/disable the calibration procedure. The calibration
procedures are found in the “IOP Calibration Procedures” section.
