3 UCN Status Displays
3.7 HPMM Detail Status Displays
R688 HPM High-Performance Process Manager Service 239
December 2020 Honeywell
HPMM IOM I/O Link Information display
The target that produces the HPMM IOM I/O Link Information display and the accompanying three
displays is available only for the primary HPMM. One of the three displays is shown in the following
figure.
Figure 124 IOM I/O Link Information Display
Data tables
The display shows the current I/O Link status for the primary and the secondary (if present) IOP, in the
High-Performance Process Manager. Up to 40 IOPs are configurable in the HPM. The information is
given in a tabular form. IOPs are arranged in the order of their module number on the I/O Link Interface.
The data table is displayed on three pages. Page 1 displays the data for modules 1-15, page 2 for modules
16-30, and page 3 for modules 31-40. The 01...15, 16...30, or 31...40 target is used to select the desired
display. For both the primary and secondary IOP (if it exists), there are seven subcolumns. The
subcolumn labels are described in the table that follows. =Data for “configured-but-not responding” IOPs
appears in red.
The displayed data is snapshot data that is updated every 4 seconds. The REFRESH VALUES target
can be used to update the displayed data.
