3 UCN Status Displays
3.7 HPMM Detail Status Displays
R688 HPM High-Performance Process Manager Service 241
December 2020 Honeywell
HPMM Version/Revision Display
The selection of the VER/REVIS target on the I/O Link Information display invokes the HPMM
Version/Revision display shown in the following figure which shows the current
version/revision/personality information for the hardware and software present in the HPMM.
Figure 125 HPMM Version/Revision Display
With R684, two new fields are added. The Node Type field displays either HPM or EHPM depending
on type of node. The Media Type field displays TBC for an HPM, or FTE for an EHPM.
