4 Fault Isolation
4.14 Power System Voltage Checks
388
HPM High-Performance Process Manager Service
R688
Honeywell
December 2020
AC Only Pow
er System
Voltage test poin
ts
Refer to Figure
188
for identificatio
n the voltage po
ints listed in the following table.
Table
84
AC Only Power System Voltag
e Test Points
Voltage Test Point
Acceptable Range
Corrective Action
AC Input
120 Vac
230 Vac
100 to 132 Vac
187 to 264 Vac
Check ac power source.
Power Supply Module
Common
DC Out (24 Vdc)
Connector Pins 3 and 4
(6 Vac for clock)
None
24 to 26 Vdc
2.0 to 6.0 Vac
Common reference
Replace Power Supply Mod
ule.
Replace primary (left) Power
Supply Module.
CMOS Battery Backup
Alkaline Battery
(Set of 3)
1.2 to 1.5 Vdc
(across 1 battery)
3.6 to 4.5 Vdc
(across 3 batteries)
Replace the batteries.
