4 Fault Isolation
4.3 Fault Isolation Concepts
304 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Recommendations for Operators and Service Technicians
The flowchart shown in the following figures have been developed for use by both a Universal Station
(US) Operator and the Service Technician.
Figure 180 HPM Fault Isolation Flowchart (Sheet 1 of 6)
Figure 181 HPM Fault Isolation Flowchart (Sheet 2 of 6)
Figure 182 HPM Fault Isolation Flowchart (Sheet 3 of 6)
Figure 183 HPM Fault Isolation Flowchart (Sheet 4 of 6)
Figure 184 HPM Fault Isolation Flowchart (Sheet 5 of 6)
Figure 185 HPM Fault Isolation Flowchart (Sheet 6 of 6)
The flowchart shows the Operator how to use the displays to locate the error code. When the error code
is identified, the Service Technician can begin to further define/resolve the fault by using the error code
tables and associated corrective action recommendations.
After a fault has been isolated to a particular High-Performance Process Manager subassembly, refer to
the “IOP Calibration Procedures” section for the applicable removal and replacement procedures.
Troubleshooting table usage
Use the following tables in this section in conjunction with the troubleshooting activities guided by the
HPM troubleshooting flow chart. There will be specific references (exit points) to these tables given in
the troubleshooting flowchart.
Table 57 HPMM Corrective Actions
Table 58 Communications and Control Processor Hard Failure Codes (covers both HMPP
Communications and Control processor Hard failures).
Table 59 Comm/Control Soft Failure Error Codes
Table 60 I/O Link Hard Failure Error Codes
Table 61 IOP Hard Failure Error Codes
Table 62 IOP Box Soft Failure Error Codes
Table 63 IOP Slot Soft Failure Error Codes
Table 64 HPMM Card and Module Indicators
Table 68 Alphanumeric Display for a Normal Startup Sequence
Table 69 Alphanumeric Display for Startup/Factory Test Mode Sequence
Table 70 Alphanumeric Display for HPMM Cold Startup Failure Sequence
Table 71 Alphanumeric Display for Load Sequence
Table 72 Communications/I/O Link Processor Failure Display Sequence
Table 73 Control Processor Failure Display Sequence
Table 74 RAM Retention Startup Display Sequence
Table 75 Alphanumeric Display for HPMM Swapping Sequence (Detailed Display Mode)
Table 76 Alphanumeric Display for HPMM Swapping Sequence (Non-Detailed Display Mode)
Table 77 Alphanumeric Display for Failover HPMM Swapping Sequence (Detailed Display Mode)
Table 78 Alphanumeric Display for Failover HPMM Swapping Sequence (Non-Detailed Display
Mode)
Table 79 HPMM Diagnostic Test List
Table 80 IOP Card Indicators
