Honeywell HPM User Manual

3 UCN Status Displays
3.8 IOP Detail Status Displays
R688 HPM High-Performance Process Manager Service 299
December 2020 Honeywell
The IOP PI Loading Information display information and targets are defined in the following table.
Table 56 IOP PI Loading Information Display
Term
Description
UCN
Displays the UCN address on the LCN. Also, a target to return
to the UCN Status display.
HPM
Displays the HPM address on the UCN. Also, a target to
return to the HPM Status display.
IOM
Displays the IOP address in the HPM. Also, a target to return
to the Fieldbus IOP Detail Status display.
PERSONALITY
LOCK
Lock code, which is a combination of a Universal key code
and a unique code specific to Fieldbus IOP. This would be
expanded in the future for other Field Programmable IOPs.
Appropriate key is send down during the PI Load, which is
verified against this lock before Programming the PI.
CURRENT PI FILE
NAME
This is the name of the file that is currently loaded in the
Fieldbus IOP.
NEXT PI FILE NAME
This is the name of the file that is being loaded in the Fieldbus
IOP.
STATUS
Status of the PI Load. Shows Initial, Transient as well as Final
states.
LOADING NODE
UCN Node Number of the NIM that has locked the current IOP
for PI Loading.
PACKET NUMBER
Current packet number during the load and total number of
packets after the load is complete.
IDENTIFIER
Unique description for the Fieldbus IOP
KEY
Code embedded in the first packet that comes down during
Program Load. This key code is verified against the
Personality Lock and the Program Load continues only with
the right key-lock combination. A universal key could be send
down which would override any lock.
VERSION
Software Version Number of the current PI in the IOP.
REVISION
Software Revision Number of the current PI in the IOP.
