Honeywell HPM User Manual

9 Spare Parts
9.2 Periodic Maintenance Parts
R688 HPM High-Performance Process Manager Service 483
December 2020 Honeywell
Conformally coated ORU parts list
The following table is a parts list of confomally coated HPM ORU assemblies.
Table 89 Conformally Coated HPM ORU Parts List
Name
Description
Part Number
POWER SYSTEM COMPONENTS
Power Supply Module
Standard 20 A Power Supply Module
(Replaced by 51198651-100)
51109456-200
(obsolete)
Power Supply Module
AC Only 8 A Power Supply Module
51190465-150
Power Supply Module
AC Only 16 A Power Supply Module
51190465-250
48 V Battery Backup
48 V Battery Pack assembly
51303948-100
Power System Backpanel Assy
PM/APM Power System backpanel
51401166-150
Power System Backpanel Assy
HPM Power System backpanel
51404172-150
AC/DC Distribution Assembly
AC Only power control and distribution board 115 Vac
dual PSMs
51401135-150
AC/DC Distribution Assembly
AC Only power control and distribution board 115 Vac
single PSM
51401135-250
AC/DC Distribution Assembly
AC Only power control and distribution board 230 Vac
dual PSMs
51401135-350
AC/DC Distribution Assembly
AC Only power control and distribution board 230 Vac
single PSM
51401135-450
CMOS Battery Backup Assembly
PM/APM Charger/monitor for CMOS memory
51303968-150
CMOS Battery Backup Assembly
HPM PS charger/monitor for CMOS memory
51309206-150
HPMM CARDS/MODULE
High-Performance Comm/Control
Communications/Control card
51401635-150
(obsolete)
51403988-150
High-Performance I/O Link
I/O Link Interface card
51309276-150
HPM UCN Interface
UCN Interface module
51402573-100
(obsolete)
51402573-250
(obsolete)
51402573-450
IOP CARDS
HLAI IOP (MC-PAIH02)
High Level Analog Input card
51304489-150
HLAI IOP (MC-PAIH03)
High Level Analog Input card
51304754-150
LLAI IOP (MC-PAIL02)
Low Level Analog Input card
51304481-150
LLMux IOP (MC-PLAM02)
Low Level Multiplexer card
51304362-150
