Honeywell HPM User Manual

4 Fault Isolation
4.3 Fault Isolation Concepts
340 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Table 59 Comm/Control Soft Failure Error Codes
Bit
Position
Failure Mnemonic
Display Text
Corrective
Action
(See Table 57)
86
SPARE110
UART ACCESSIBILITY ERROR
6, 1
87
SPARE110
BATTERY BACKUP CIRCUITRY FAIL
6, 1
88
STCKLIM
IOL PROC STACK LIMIT OVERFLOW
7, 1
89
SPARE110
EHPM REDUN PORT NOT CONNECTED
9
90
SPARE110
1
91
WDTOFF
WATCH DOG TIMER DISABLED
6, 1
92
CTL_NOTG
NO TOG FROM CTRL PROCESSOR
6, 1
93
DRM_SBE
GLOBAL DRAM EDAC SBE Hl-RATE
6, 1
94
CTL CE
CTRL CONSOLE EMULATOR UNLOCKED
17
95
COM_CE
COMM CONSOLE EMULATOR UNLOCKED
17
I/O Link processor Hard failure error codes
Table 60 I/O Link Hard Failure Error Codes provides the I/O Link processor Hard failure codes.
The corrective action(s) that are identified in the table are located in Table 57 HPMM Corrective
Actions.
Table 60 I/O Link Hard Failure Error Codes
Error code
Failure
Mnemonic
Description
Corrective Action
(See Table 57 HPMM
Corrective Actions)
00
UNKNOWN
Unknown Hard Failure.
None
01
POWERDWN
Powerdown occurred.
None
02
I NVPRGEX
Unused on I/O Link interface
1
03
EPROMERR
Program checksum error.
2, 7, 1
04
RAMCNTER
RAM contents error.
2, 7, 1
05
RAMADRER
RAM address decoding error.
7
06
DPAERROR
Device Physical Address (DPA) error.
2, 7, 1
07
DSAERROR
Device Soft Address (DSA) error.
2, 7, 1
08
RXBUFOFL
Unused on I/O Link interface
1
09
IOLJA8ER
I/O Link jabber circuit fired.
7
0A
SRAMFAIL
Unused on I/O Link interface.
1
0B
BADPGJMP
Unused on I/O Link interface.
1
0C
ADCINCMP
Unused on I/O Link interface
1
