4 Fault Isolation
4.3 Fault Isolation Concepts
R688 HPM High-Performance Process Manager Service 339
December 2020 Honeywell
Table 59 Comm/Control Soft Failure Error Codes
Bit
Position
Failure Mnemonic
Display Text
Corrective
Action
(See Table 57)
56
LCCKSMFL
1
57
LCIOPPWFL
1
58
LCSWDTFL
IOL PF BUF SIZE EXCEEDED
19
59
LCBATTFL
IOL PS BUF SIZE EXCEEDED
19
60
PCSLFTST
UCN PF BUF SIZE EXCEEDED
19
61
LCSIOMOL
UCN PS BUF SIZE EXCEEDED
19
62
CTLSTACK
CTRL PROC STACK LIMIT OVERFLOW
2, 6, 1
63
LCIOCDFL
1
64
IOLIUNKN
1
65
IOLISTCO
IOL PROC STC OVERRUN
2, 7, 1
66
IOLIREQO
IOL PROC TASK REQUEST OVERFLOW
2, 7, 1
67
IOLIBADR
IOL PROC RESUME NON-WAIT TASK
2, 7, 1
68
IOLIDIAT
IOL PROC DIAG INIT TIMEOUT
2, 1
69
IOLIDIAO
IOL PROC DIAG CYCLE OVERFLOW
2, 7, 1
70
IOLIFTAN
1
71
IOLCBL1A
IOL CABLE 1A FAILURE
10, 7, 1
72
IOLCBL1 B
IOL CABLE 1 B FAILURE
10, 7, 1
73
IOLCBL2A
IOL CABLE 2A FAILURE
1
74
IOLCBL2B
IOL CABLE 2B FAILURE
1
75
SPARE110
NO RESPONSE FROM IOL#2
1
76
SPARE110
IOL #2 WATCH DOG TIMER EXPIRED
1
77
SPARE110
TIMESYNCH IOL #2 LATCH ERROR
1
78
SPARE110
NO PRIMARY IOL2 COMM TO SECNDY
1
79
SMBATSFL
1
80
SMTSFLT
1
81
LCTSFLT
1
82
IOL_HMRG
HIGH POWER SUPPLY MARGINING
13
83
IOL_LMRG
LOW POWER SUPPLY MARGINING
13
84
IOLIPERR
IOL DETECTED IOL PERR Hl-RATE
7, 1
85
IOLPCHKR
IOL DETECT IOL RAM PARITY CKT
7,1
