9. Spare Parts
9.1 Overview
Introduction
The parts listed in the following tables are periodic maintenance items and Optimum Replaceable Units
(ORU) for the High-Performance Process Manager (HPM). All the listed parts reference the Honeywell
part number. For additional or optional equipment part numbers not listed, contact your Honeywell Sales
Representative.
9.2 Periodic Maintenance Parts
Periodic maintenance parts list
Table 87 HPM Periodic Maintenance Parts lists items that may be required during the life of the
High-Performance Process Manager.
Table 87 HPM Periodic Maintenance Parts
Name
Description
Part Number
BATTERIES
NiCad Rechargeable Batteries
One AA-size NiCad battery
51190422-100
One C-size NiCad battery
51192060-100
Alkaline Batteries
One AA-size Alkaline battery
51190467-100
FUSES
Assembly
Quantity
Description
Left 7-Slot Card File (51401626)
8
2.0 A Subminiature fuse (F1-8)
30754661-021
Right 7-Slot Card File (51401629)
8
2.0 A Subminiature fuse (F1-8)
30754661-021
15-Slot Card File (51401629)
16
2.0 A Subminiature fuse (F1-16)
30754661-021
IOP Card File (51402599)
15
2.0 A Subminiature fuse (F1-15)
30754661-021
1
0.5 A Subminiature fuse (F16)
30754661-014
3-30 Vdc SS DO FTA (51304423)
16
5.0 A Time-delay fuse 5 x 20 mm
51190584-250
3-30 Vdc SS DO FTA (51304650,
51309153)
16
2.5 A Time-delay fuse 5 x 20 mm
51190584-225
31-200 Vdc SS DO FTA (51304428,
51309154)
16
1.0 A Time-delay fuse 5 x 20 mm
51190584-210
24-240 Vac SS DO FTA (51304408)
16
3.0 A Time-delay fuse 5 x 20 mm
51190584-230
120/240 Vac SS DO FTA (51304648)
16
2.5 A Time-delay fuse 5 x 20 mm
51190584-225
120 Vac Relay DO FTA (51304443,
51309148)
16
6.0 A Time-delay fuse 5 x 20 mm
51190584-260
240 Vac Relay DO FTA (51304427,
51309150)
16
3.0 A Time-delay fuse 5 x 20 mm
51190584-230
