Honeywell HPM User Manual

9 Spare Parts
9.2 Periodic Maintenance Parts
466 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Table 87 HPM Periodic Maintenance Parts
Name
Description
Part Number
24 Vdc Nonisolated DO FTA (51304446)
16
0.2 A Fast-action fuse 5 x 20 mm
(F1-16)
51190582-120
1
2.0 A Fast-action fuse 5 x 20 mm
(F17)
51190582-220
24 Vdc Isolated DO FTA (80364013)
4
1.6 A Fast-action fuse MP16 (F1-4)
83957061-004
24 Vdc Isolated DO FTA (80366183)
16
1.6 A Fast-action fuse MP16 (F1-16)
83957061-004
LLAI FTA (51304437, 51309202)
4
0.5 A Subminiature fuse (F1-4)
30754661-014
DI FTA (80364010, 80366180)
2
0.5 A Fast-action fuse MP05 (F1,
F3)
83957061-002
DI FTA (80364010, 80366180)
1
1.0 A Fast-action fuse MP10 (F2)
83957061-003
DI Power Distribution Assy (51304425)
12
1.0 A Fast-action fuse 5 x 20 mm
(F1-12)
51190582-210
SI/SDI FTA (51303932)
2
0.25 A Subminiature fuse (F1-2)
30754661-011
Nonredundant AO FTA (51304476)
2
1.0 A Fast-action fuse 5 x 20 mm
(F1-2)
51190582-210
Redundant AO FTA (51304335)
3
1.0 A Fast-action fuse 5 x 20 mm
(F1-3)
51190582-210
Redundant AO FTA (80364007,
80366177, 80366481, 80366484)
1
1.0 A Fast-action fuse MP10 (F1)
83957061-003
Pulse Input FTA (51304084)
8
0.25 A Fast-action fuse 5 x 20 mm
(F1-8)
51190582-125
Galvanic AO FTA (51304638)
3
1.0 A Subminiature fuse (F1-3)
30754661-019
GI Power Distribution Assy (51304644)
8
4.0 A Fast-action fuse 5 x 20 mm
(F1-8)
51190582-240
H-P I/O Link Card
1
3.0 A Fast-action fuse (F1)
30754661-022
Fuseholder Puller
Fuseholder extractor
51190586-100
FILTERS
Filter Kit (Rittal cabinet)
Louvered cover and filter, 20 /8 x 20 /8 (cm/in.)
51109488-100
Filter (Rittal cabinet)
Replacement filter only, 20 /8 x 20 /8 (cm/in.)
51109488-200
Filter (Markhon cabinet)
Replacement filter only, 39 /15.5 x 61 /24 (cm/in.)
51109541-100
