4 Fault Isolation
4.3 Fault Isolation Concepts
320 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Table 58 Communications and Control Processor Hard Failure Codes
Error
Code
CPU
Failure Mnemonic
Description
Corrective Action
(See Table 57)
007F
Comm
CHGFILE
File address/parity jumpers have
changed
5, 6, 11, 1
0080
Comm
CHGSLOT
Slot address/parity has changed
6, 11, 1
0081
Both
RSTCTL
Unused on HPM Platform
1
0082
Comm
Fl_COM
Fault insertion Comm crash
1
0083
Control
Fl_CTL
Fault insertion Control crash
1
0084
Control
Fl_PTRN
Fault insertion pattern comparison
failure
1
0085
Both
UART_ACC
UART access error
2, 6
0086
Both
NO_HB
The other processor (Communications
or Control) has no heatbeat.
2,6
0087
to
00FF
Both
Undefined
Reserved for future Hard failure codes.
1
0100
to
01FF
Comm
CRASH
UCN Token Bus Controller command
timeout. These errors occur if the
UTBC does not complete a
non-modem related command.
6,1
0200
to
02FF
Comm
CRASH
Physical/MAC command to UTBC
timeout. These errors occur if the
UTBC does not complete a modem
related command.
8, 6, 11, 1
0300
Comm
CRASH
Modem A failed to ACK reset in
initialization
8, 6, 11, 1
0301
Comm
CRASH
Modem B failed to ACK reset in
initialization
8, 6, 11, 1
0302
Comm
CRASH
Modem A failed to ACK reset in jabber
test
8, 6, 11, 1
0303
Comm
CRASH
Modem B failed to ACK reset in jabber
test
8, 6, 11, 1
0304
Comm
CRASH
Corrupted TX counter
2, 1
0305
Comm
CRASH
No free FD for TX to test
2, 1
0306
Comm
CRASH
No free FD for TX for resynch
2, 1
0307
Comm
CRASH
No free FD for TX for message
2, 1
0308
Comm
CRASH
Modem failed to ACK Enable Channel
A command
8, 6, 11, 1
0309
Comm
CRASH
Modem failed to ACK Enable Channel
B command
8, 6, 11, 1
