Honeywell HPM User Manual

4 Fault Isolation
4.3 Fault Isolation Concepts
328 HPM High-Performance Process Manager Service R688
Honeywell December 2020
Table 58 Communications and Control Processor Hard Failure Codes
Error
Code
CPU
Failure Mnemonic
Description
Corrective Action
(See Table 57)
068F
Comm
CRASH
Timed event flag failed.
2, 1
068C
to
06BF
Comm
CRASH
Reserved for future GBL Subsystem
crash codes.
1
06C0
to
06C2
Both
CRASH
Unused on HPM Platform.
1
06C3
Both
CRASH
Comm to Control interrupt failure.
2, 6, 1
06C4
Both
CRASH
Control to Comm interrupt failure.
2, 6, 1
06C5
Comm
CRASH
I/O Link code in wrong location.
1
06C6
Comm
CRASH
I/O Link code wrong size.
1
06C7
to
06DC
Comm
CRASH
Reserved for future miscellaneous
crash codes.
1
06DD
Comm
CRASH
Control processor startup failure.
6, 1
06DE
Comm
CRASH
I/O Link processor(s) startup failure.
7, 6, 1
06DF
Comm
CRASH
Bad common memory signature.
1
06E0
Comm
CRASH
CPU Free change priority fail #1.
2, 1
06E1
Comm
CRASH
CPU Free change priority fail #2.
2, 1
06E2
Comm
CRASH
CPU Free pause fail.
2, 1
06E3
Comm
CRASH
Could not set CPU Free LEF.
2, 1
06E4
Comm
CRASH
Could not reset CPU Free LEF.
2, 1
06E5
Comm
CRASH
Could not reset Timer Comparison
LEF.
2, 1
06E6
Comm
CRASH
Could not set Timer Comparison LEF.
2, 1
06E7
to
06EF
Comm
CRASH
Reserved for future high priority task
crash codes.
1
06F0
Comm
CRASH
Could not set Peer to Peer Statistics
LEF.
2, 1
06F1
Comm
CRASH
Could not reset Peer to Peer Statistics
LEF.
2, 1
06F2
Comm
CRASH
Could not reset Diagnostic Overflow
LEF.
2, 1
06F3
Comm
CRASH
Could not set Diagnostic Overflow
LEF.
2, 1
06F4
to
06FF
Comm
CRASH
Reserved for future high priority task
crash codes.
1
