Honeywell HPM User Manual

4 Fault Isolation
4.3 Fault Isolation Concepts
R688 HPM High-Performance Process Manager Service 333
December 2020 Honeywell
Table 58 Communications and Control Processor Hard Failure Codes
Error
Code
CPU
Failure Mnemonic
Description
Corrective Action
(See Table 57)
0B0D
Comm
CRASH
Wait swap EF failure.
2, 1
0B0E
to
0B7F
Comm
CRASH
Reserved for future Supervisor
Subsystem crash codes.
1
0B80
Comm
CRASH
Illegal task invocation.
2, 1
0B81
Comm
CRASH
Set timed EF failure.
2, 1
0B82
Comm
CRASH
Illegal wait for EF
2, 1
0B83
Comm
CRASH
Illegal pause status.
2, 1
0B84
Comm
CRASH
Reset EF failure.
2, 1
0B85
to
0BFF
Comm
CRASH
Reserved for future IOP Failover
Subsystem crash codes.
1
0C00
Comm
CRASH
Operating system has no SRBs
available.
2,1
0C01
Comm
CRASH
Bad MMU alignment.
1
0C02
to
0CFF
Comm
CRASH
Reserved for future Operating system
(MTOS) Subsystem crash codes.
1
0D00
to
0D0F
Both
CRASH
Unused on HPM platform.
1
0D10
Both
CRASH
SW EDAC unrecoverable Local RAM
PERR.
2, 6,1
0D11
Both
CRASH
SW EDAC multiple Local RAM PERRs
failure.
2, 6, 1
0D12
Comm
CRASH
SW EDAC unrecoverable I/O Link
RAM PERR.
2, 7, 1
0D13
Comm
CRASH
SW EDAC multiple I/O Link RAM
PERRs failure.
2, 7, 1
0D14
to
7FFF
Comm
CRASH
Reserved for future Comm crash
codes.
1
8000
to
FFFF
Comm
CRASH
Unused by Communications
processor.
1
8000
to
FFD9
Control
CRASH
Reserved for future Control crash
codes.
1
FFDA
Control
CRASH
Flush address out of Control database
boundary.
2, 6, 1
FFDB
Control
CRASH
Illegal SIZ-A1A0 combination.
2, 6, 1
