Honeywell HPM

9 Spare Parts
9.2 Periodic Maintenance Parts
R688 HPM High-Performance Process Manager Service 491
December 2020 Honeywell
Table 89 Conformally Coated HPM ORU Parts List
Name
Description
Part Number
number MTL4523 – 51202956-100)
LFD Combiner Panel (MC-GLFD02)
Line Fault Detection Combiner Panel
51304732-175
Power Distribution Assembly (MC-
GPRD02)
Galvanic Isolation Power Distribution Assembly
51304644-175
Marshalling Panel (MC-GMAR52)
Marshalling Panel
51309156-175
FBUS (MC-GTBS01)
Fieldbus FTA with GI/IS PS module (Comp Term
51309254-275
FBUS (MC-GTBS71)
Fieldbus FTA with GI/IS PS module (Crimp Term)
51309254-475
Plug-in GI/IS module (MTL4053) for above FTAs
51192537-100
Bus terminator enable jumper for above FTAs
30731549-002
GI Module Connector
Comp-type terminal connector for GI modules
51191738-100
Crimp-type terminal connector for GI modules
51191737-100
14-20 AWG wire crimp pins for above connector
51191737-201
MISCELLANEOUS COMPONENTS (continued)
Cabinet Fan Assembly
Cabinet fan assembly, 115 Vac without alarm
51304074-150
Cabinet fan assembly, 230 Vac without alarm
51304074-250
Cabinet Fan
Fan, 115 Vac (replacement for 51304074-100)
68A8976P1
Fan, 230 Vac (replacement for 51304074-200)
68A8976P2
Cabinet Fan Assembly
Cabinet fan assembly, 115 Vac with alarm
51303940-150
Cabinet fan assembly, 230 Vac with alarm
51303940-250
Cabinet Fan Assembly PWB
PWB, 115 Vac (replacement for 51303940-150)
51201475-150
PWB, 230 Vac (replacement for 51303940-250)
51201475-250
Left 7- Slot Card File (MC-HPFH01)
Left 7-Slot HPMM/IOPcard file assy (slots 1-7)
51404125-150
Left 7- Slot Card File (MC-HPFH03)
Left 7-Slot HPMM card file assy (slots 1-7)
51404191-175
Left 7- Slot Card File (MC-HPFI03)
Left 7-Slot IOP card file assy (slots 1-7)
51404191-275
Left 7- Slot Card File Backpanel
Left 7-Slot card file backpanel assy (slots 1-7)
51401626-150
Right 7- Slot Card File (MC-HPFH11)
Right 7- Slot HPMM/IOP card file assy (9-15)
51404126-150
Right 7- Slot Card File (MC-HPFH13)
Right 7- Slot HPMM card file assy (slots 9-15)
51404192-175
Right 7- Slot Card File (MC-HPFI13)
Right 7- Slot IOP card file assy (slots 9-15)
51404192-275
Right 7- Slot Card File Backpanel
Right 7- Slot card file backpanel assy (slots 9-15)
51401629-150
15-Slot Card File (MC-HPFX02)
15-Slot HPMM/IOP card file assy (slots 1-15)
51404127-150
15-Slot Card File (MC-HPFX03)
15-Slot HPMM card file assy (slots 1-15)
51404193-175
