18. Appendix 5 - User Interface Software Menu Structure
18.1.4 Calibration from the Local User Interface (Touchscreen)
• Sensor Signal
• Gas Concentration
• Calibration (last & due) Date
• Fault
• Warning
• Inhibit
Access to:
• Gas Calibration / Span Adjust
• Gas Calibration / Zero Adjust
• Gas Calibration / First Span Adjust
• Sensor Signal
• Span Gas Concentration
• Ask for applying specfic gas
• Ask for entering applied
concentration
• Button for accepting span
• Show measured gas value
• Ask for applying clean air
• Button for accepting zero value
• Sensor Signal
• Span Gas Concentration
• Ask for applying specific gas
• Ask for entering applied
concentration
• Button for accepting span
Calibration
First Span Adjust
(mV Only)
Zero AdjustSpan Adjust
