Honeywell touchpoint Pro User Manual

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
3
4.3 Cabling Requirements 45
4.3.1 Ring Network 46
4.3.2 Field devices 46
4.3.3 Power Supplies 46
4.3.4 Bus interfaces 46
4.3.5 Ethernet 46
4.3.6 Touchpoint Pro Battery Box 46
4.4 Cabling Requirements – Additional info for assembly by system integrators 47
4.4.1 24 Vdc Power - Controller 47
4.4.2 Internal network connections 47
4.5 Ring Network Distance Restrictions 47
4.6 Earthing 48
4.7 EMC / RFI Considerations 50
4.8 Electrical Connections 51
4.8.1 Touchpoint Pro Power Supplies 51
4.8.1.1 120 W 24 Vdc Power Supply Unit 51
4.8.1.2 240 W 24 Vdc Power Supply Unit 52
4.8.1.3 480 W 24 Vdc Power Supply Unit 53
4.8.2 Power Redundancy Module 54
4.8.3 UPS and Battery Box 55
4.8.4 Analogue Input Module 4-20 mA 57
4.8.5 Analogue Input Module mV Bridge 60
4.8.6 Digital Input Module 61
4.8.7 Relay Output Module 62
4.8.8 Ring Coupling Module 64
4.8.9 System State Relays 66
4.8.10 Power Supply Unit Status Inputs 66
5 User Interface 68
5.1 General 68
5.2 Access Levels 68
5.3 User Interface Software 71
5.4 Local Interface (Touchscreen) 72
5.5 Web Server 72
 5.6 PCCongurationSoftware 73
5.7 SD Card 73
5.8 Interfaces 73
6 Commissioning 75
6.1 Introduction 75
6.2 First Time Switch On 75
6.3 Set Date, Time and Language 76
6.4 Program Users and Passwords 77
6.5 Setup Web Server 78
6.5.1 TCP/IP Settings 78
6.5.2 Internet Explorer 8 Settings 79
6.5.3 Windows Settings 79
 6.6 SetupPCCongurationSoftware(optional) 79
 6.7 VerifyDefaultCongurationandProgramTags 81
6.8 Commission Input / Output Modules 82
 6.9 ChannelConguration 83
6.9.1 Introduction 83
  6.9.2 ConguringaChannel 84 
  6.9.3 EditingaConguredChannel 85
6.9.4 Removing an I/O Module 85
Contents
