MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
4
6.10 Commission Power Supply Unit Status Channels 86
 6.11 RedundantControlCentreBoardConguration 86
6.12 Buzzer Activation and Button Password Protection 87
 6.13 TouchPanelConguration 88
6.13.1 Calibrate touch panel 89
6.14 Service Contact Settings 88
 6.15 BackupConguration 88
6.16 Calibrate mV input channels 89
6.17 Calibrate mA input channel loops 90
7 Normal Operation 92
7.1 Safety Function 92
7.2 Overview - Touchscreen Interface 92
7.2.1 System Status screen 92
7.2.2 Navigation - Inputs and Outputs Screens 94
7.2.3 Navigation - Active Events 95
7.2.4 Login 95
7.3 Overview – Web Server Interface 96
7.3.1 Start the Web Server 96
7.3.2 System Status Screen 96
7.3.3 Navigation – Inputs and Outputs Screens 98
7.3.4 Navigation – Active Events 99
7.3.5 Navigation – Extras 99
7.4 Alarms 100
7.4.1 View active alarms 100
7.4.2 Acknowledge an active alarm 101
7.4.3 Reset a latched alarm 101
7.5 Faults and Warnings 102
7.5.1 View Faults and Warnings 102
7.5.2 Acknowledge an active Fault or Warning 102
7.5.3 Reset a latched Fault or Warning 103
7.6 Inhibit 103
7.7 View Input Channels and Input Details 104
7.8 View Output Channels 105
7.9 View Trend Graph 107
7.10 View Event History 108
7.11 Generate Reports 108
7.12 Access Diagnostic information 109
7.13 Check the capacity of the SD Card 109
7.14 Access Help 109
7.15 System State Relays 109
8 Maintenance 110
8.1 Testing the Touchpoint Pro System 110
8.1.1 Introduction 110
8.1.2 Field Inputs Test 111
  8.1.3 CongurationSettingsTest 112
8.1.4 Cause and Effect Test 113
8.2 Routine maintenance 114
8.3 Exercise the relays 114
8.4 How to replace a faulty I/O module 115
8.5 How to add a new I/O Module 119
8.6 How to Remove or Decommission an I/O Module 120
 8.7 Backup/Restoreconguration 122
8.8 Change the SD Card 123
Contents
