MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
5
8.9 Calibrate mV input channels 123
8.10 Touchpoint Pro Battery Box 126
8.10.1 DC-UPS LED Indications 126
8.10.2 Routine maintenance 128
8.10.3 Changing a fuse 128
8.10.4 Replacement Batteries 128
9 Problem Solving 129
9.1 Troubleshooting 129
9.2 List of Error Codes 132
9.3 Further Assistance 143
10 Specications 144
10.1 Rack Mounted Equipment 144
10.1.1 Touchpoint Pro User Interface only 144
10.1.2 19” 5U Rack Enclosure with User Interface 144
10.1.3 19” 5U Remote Unit Enclosure without User Interface 145
10.2 Wall Mounted Enclosures 145
10.2.1 CommonSpecications 145
10.2.2 Analogue Input Module mA 146
10.2.3 Analogue Input Module mV Bridge 146
10.3 Floor Standing Enclosures 147
10.3.1 Floor Standing Cabinets Front Access 148
10.3.2 Floor Standing Cabinets Rear Access 148
10.4 Power Supplies and Fuses 148
10.4.1 PowerSupplyUnits(OEMSpecications) 148
10.4.2 DIN Rail (Module Supply and Communication) 149
10.4.3 Ring Coupling Module (RCM) 149
10.4.4 Backplane 149
10.4.5 Power Supply Redundancy Module (RDN Module) 150
10.4.6 Uninterruptible Power Supply Module (UPS) 150
10.4.7 Backup Batteries 151
10.4.8 Cabinet DC Fuses 151
10.5 Control Module and User Interface 152
10.5.1 Controller & Remote Unit DC Input Supply 152
10.5.2 Control Module and User Interface 152
10.6 I/O Modules 152
10.6.1 CommonSpecications 152
10.6.2 Analogue Input Module mA 153
10.6.3 Analogue Input Module mV Bridge 153
10.6.4 Digital Input Module 154
10.6.5 Relay Output Module 154
11 Certication 155
11.1 EC declaration of conformity 155
11.2 Applicable National and International Standards 155
11.3 NationalandInternationalCerticates 156
12 Ordering Information 158
12.1 TPPR-MInputandOutputCongurator(I/OCongurator) 158
12.2 Touchpoint Pro Control System Part Number Generator 160
12.3 TPPR-V Controllers and Remote Units 161
12.4 TPPR-H Enclosures 163
12.5 TPPR-W PSUs 175
13 Honeywell Analytics Product Warranty 176
14 Appendix 1 - Modbus Option 177
Contents
