MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
67
4. Electrical Installation
ThePSUStatusInputsaresuppliedwiththefollowingconguration.
PSU Status Input Function
1 PSU–DCOK
2 UPS – BAT RDY
3 UPS – BAT RPL
4 Temperature Sensor (Forced Ventilation Only)
IftheUPSortheforcedventilationoptionsarenotbeingused,thoseinputscanbeconguredbytheuser
to act as Global Acknowledge, Global Reset or Global Inhibit.
TPPR
PSU Status
+24 Vdc
Stat 1
Stat 2
1.0 KΩ
75 Ω
0 Vdc
Figure 4.21 PSU Status Input
