Chapter 6, Call Processing Subsystem
Using the Call Processing Subsystem
Using the Call Processing Subsystem
In order to use the Call Processing Subsystem, a mobile station must be powered
on, and connected to the Test Set.
Connecting A Mobile Station
Figure 17, "Connecting a Mobile Station to the Test Set," on page 119 shows a
typical example of how to connect a mobile station to the Test Set. You may need
a special fixture to access the mobile station’s antenna, audio in, and audio out
signals. These fixtures are available from the mobile station’s manufacturer.
If any audio testing is to be done on the mobile station, the audio input
(microphone input) to the mobile station and the audio output (speaker output)
from the mobile station must be connected to the Test Set. If no audio testing is to
be done only the antenna needs to be connected to the Test Set.
