Accessories

Table 17 Accessories

Description HP 8920A

Telescoping Antenna 08920-61060

Microphone 08920-61059

DC Battery Pack (24V) 08920-80027

Battery Charger 08920-80028

CRT Sun Shade 08920-61051

Connector Kit (one each: dc power, MIC/ACC, RS-232, RJ-11, and radio interface

connectors)

08920-61061

DC Power Connector Housing (Qty 1) 1251-4782

DC Power Connector Contacts

(Qty 2)

1252-0385

System Rack Mount Flange Kit (Option 908) 5061-4846

Rack mount kit

for HP 8920D or

HP 8921D

08921-61037

Padded Carrying Case 1540-1130

Hardshell Transit Case 08920-90033

Passive Oscilloscope Probe

(1 MΩ/7.5pF 10:1)

HP 10435A

Passive Oscilloscope Probe

(High Z/40pF 1:1)

HP 10438A

Passive Oscilloscope Probe

(High Z/64pF 1:1)

HP 10439A

RF Detector Probe

(100 kHz to 700 MHz)

HP 34301A

Resistor Divider Probe Kit HP 54006A

Power Splitter (DC to 3 GHz, 50Ω) HP 11850C
