Chapter 3, Operating Overview
Displaying Measurements
Displaying RF Measurements
Transmitter Frequency
TX Frequency
is displayed when Tune Mode is set to Auto. (Refer to item (1)
in
figure 8 on page 57.)
Transmitter Frequency Error
TX Freq Error
is displayed when Tune Mode is set to Manual. (Refer to item
(1) in
figure 8 on page 57.)
Transmitter Power
TX Power
is only measured and displayed here when the Input Port is set to
RF In (Refer to item (2) in figure 8 on page 57). If Ant (antenna) is selected, the
measurement is replaced by four dashes (- - - -).
You can measure low power levels on the ANT IN port using the Spectrum
Analyzer.
1
Refer to the TX Power field description, on page 559 and the TX Pwr Zero field
description, on page 560
for more information on measuring transmitter power.
1. Optional on some Test Set models.
CAUTION: Connecting a signal of >200 mW to the ANT IN (antenna) port can cause instrument damage
(although internal protection circuits can typically withstand a short-duration signal of 1 or 2
Watts). If the overpower circuit is triggered, remove the signal from the ANT IN port and turn
the Test Set off and on to reset it.
