Chapter 1, Get Started
Before Connecting a Radio
Before Connecting a Radio
The RF IN/OUT port should be used for all transmitter tests when the radio is connected
directly to the Test Set. (All UUT transmitter power measurements are made through this
port). Off-the-air measurements can be made using the ANT IN port.
CAUTION: Overpower Damage — Refer to the Test Set’s front panel for maximum input power level.
Exceeding this level can cause permanent instrument damage.
Figure 1 Connecting a Radio to the Test Set
Speaker or Audio OutMic Audio InMic KeyAntenna
Radio Under Test
