Chapter 8, Signaling Decoder Screen

Using the CDCSS Decoder

AF Analyzer Settings

For proper CDCSS decoder operation, make the following AF ANALYZER

screen settings:

• Filter 1 to <20Hz HPF (Required)

• Filter 2 to 3kHz LPF (Recommended)

• Settling to Slow (Recommended)

Interpreting Decoded Data

Because CDCSS uses a continuously-repeating data stream, and there is no

framing information to tell the receiver when the code word is going to be sent,

the decoded data can result in several possible code combinations. This is why

more than one code word may be listed in the

Codes (oct) column after

decoding.
