HP 8920A - IF F L; SEND F; SEND F N; Valid Channel Assignments

333
Chapter 8, Signaling Decoder Screen
Creating NMT Tests
SEND f
Send the designated frame
f.
Valid entries for the parameter f are as follows: 1A, 1A’ or 1AP, 1A’’ or 1APP, 1AS, 1A’S
or 1APS, 1A’’S or 1APPS, 1B, 1BS, 1BTA1, 1BTA2, 2A, 2A’ or 2AP, 2A’’ or 2APP, 2B,
2B’ or 2BP, 2B’’ or 2BPP, 2C, 2C’ or 2CP, 2C’’or 2CPP, 2D, 2D’ or 2DP, 2D’’ or 2DPP, 2E,
2F, 3A, 3A1, 3A2, 3B, 3BTA2, 3BTC2, 3C, 3D, 3DTA2, 4, 4TA2, 4B, 4BTA2, 5B, 6, 7,
10A, 10AAC, 10B, 10C, 10D, 11, 11A, 11B, 12, 13B, 15, 16, 21B, 21C, 22, 26, 27, 28
and 30.
Some of these frame types are only valid for certain NMT Standards. This will be checked
when the program is run.
SEND f n
Send the designated frame
f with the signal n. Valid entries for the parameter f with
parameters
n are as follows:
IF f l
If the received frame register contains the frame f, go to label l.
Valid entries for the parameter f include all the valid entries for f in the two SEND
statements; however, the special suffixes discussed in
"Special Frame Suffixes" on
page 325
are ignored by this instruction.
Valid entries for l are integers from 0 to 255. The specified label l must appear
somewhere before the END statement of the program.
Table 8 Valid Channel Assignments
f n
5a, 13a Line signal number: 0 to 15, or 0 to F (hex)
14a, 14b Digit signal value: 0 to 13, A to D(10 to 13), * and #.
20 Channel activation order: 0 to 15, or 0 to F (hex)
25 Channel status information: 0 to 15, or 0 to F (hex)
